Ganga Kaveri Water Tank

Test Data
Test Data
Test Data
Test Data
Outdoor Application Water Tanks
akashdoot
Sl. No. Capacity in Litres Dimensions Hole size for fittings
Diameter
Inch
Height
Inch
Manhole Dia.
Inch
Inlet
Inch
Outlet
Inch
Overflow
Inch
1 200 22.8 28.3 11 ¾ ¾ ¾
2 300 32 29.7 11 ¾ ¾ ¾
3 500 37.5 34.5 15.8 ¾ ¾ ¾
4 750 42.5 39.2 15.8 1 1 1
5 1000 48.7 42.9 15.8 1 1 1
6 1500 53.9 48.4 15.8 1 1 1
7 2000 60.2 54.7 15.8 1 1 1
8 3000 68.5 61 15.8 1 1 1
9 5000 73.6 76 15.8 1 1 1
10 6000 92.7 76 18.9 1 ½ 1 ½ 1 ¼
11 7500 114.2 76 18.9 1 ½ 1 ½ 1 ¼
12 10000 100.6 92.1 18.9 2 2 1 ½
13 15000 135.8 97.6 18.9 2 2 1 ½
14 20000 179.9 97.6 18.9 2 2 1 ½
Blow Moulded Tank
akashdoot
Sl. No. Capacity in Litres Dia
inch
Height
inch
Manhole /
Dia
1 500 34 41 15.8
2 750 39.4 46.8 15.8
3 1000 43 51 15.8
4 1500 50.25 55.15 15.8
5 2000 53.25 65.45 15.8

Loft Tank Indoor Application

akashdoot
Sl. No. Capacity in Litres Overall Dimensions Manhole
inch
length
inch
width
inch
height
inch
1 150 29 29 14.2 11.8
2 225 38 29.1 15.3 11.8
3 400 48 36.5 16 11.8
4 525 57.5 41 16 11.8

Household Drum Indoor Application

akashdoot
Sl. No. Capacity in Litres Overall Dimensions
Length
inch
Width
inch
Manhole
inch
1 100 27.8 17.6 11.8
2 150 34.2 19.7 11.8
3 200 38.2 21.3 11.8

Plumber Water Storage Tank

akashdoot
Sl. No. Capacity in Litres Dimensions Hole size for fittings
Diameter
Inch
Height
Inch
Manhole Dia.
Inch
Inlet
Inch
Outlet
Inch
Overflow
Inch
1 500 35 34.5 15.8 ¾ ¾ ¾
2 750 40 40 15.8 1 1 1
3 1000 44 44 15.8 1 1 1
4 1500 57 48 15.8 1 1 1
5 2000 63 54 15.8 1 1 1
6 3000 63 63 15.8 1 ½ 1 ½ 1 ½
7 5000 81 75 15.8 1 ½ 1 ½ 1 ½
8 10000 105 91 15.8 1 ½ 1 ½ 1 ½
